Main performance characteristics of aluminum strip butyl rubber coater

1、丁基膠涂布機為中空玻璃出產的首要設備，為半主動膠條涂布機，即人工持鋁距離框進行操作，將鋁距離框放在傳送帶上，人工持鋁距離框隨傳送帶運行，當鋁距離框經過傳感器時，傳送壓輪及打膠閥將按設定程序主動運行，即氣缸動作，壓輪壓下，壓送鋁距離框進行;待鋁距離框抵達打膠頭時開端打膠，將膠均勻地涂在鋁距離框上，當距離框另一側快要抵達壓輪時，壓輪抬起，離開打膠頭時，膠閥主動停止打膠。

1. Butyl rubber coater is the primary equipment for insulating glass production. It is a semi-active rubber strip coater, that is, the aluminum distance frame is manually held for operation. The aluminum distance frame is placed on the conveyor belt, and the aluminum distance frame is manually held for operation with the conveyor belt. When the aluminum distance frame passes through the sensor, the transmission pressure roller and the glue valve will operate actively according to the set procedure, that is, the air cylinder acts, the pressure roller is pressed down, and the aluminum distance frame is pressed; When the aluminum distance frame reaches the gluing head, start gluing, and apply the glue evenly on the aluminum distance frame. When the other side of the distance frame is about to reach the pressure roller, the pressure roller will lift up. When it leaves the gluing head, the glue valve will stop gluing actively.

2、選用人機界面顯示屏便于操作，體系以PLC為操控中心，由光電傳感PLC機、中文操控終端、PLC主動轉換。按鈕開關等電器元件組成，功用強大、作業牢靠、操作簡單主動化程度較高。

2. The human-machine interface display screen is selected for easy operation. The system takes PLC as the control center and is actively converted by photoelectric sensor PLC machine, Chinese control terminal and PLC. Button switch and other electrical components, with strong function, reliable operation, simple operation and high degree of initiative.

3、鋁條丁基膠涂布機選用目前國內較大缸徑?195膠缸，裝膠容量大，較大極限確保連續出產時刻，進步作業效率。選用較氣動增壓體系，充沛確保膠頭出膠壓力衡定，避免了打膠粗細不勻，斷膠現象。選用4段變頻調速，較大極限照料操作工人熟練程度，進步作業效率。

3. What is the current domestic cylinder diameter for aluminum strip butyl rubber coating machine? 195 rubber cylinder, large rubber loading capacity, large limit to ensure continuous production time and improve operation efficiency. The advanced pneumatic pressurization system is selected to fully ensure that the glue outlet pressure of the glue head is constant and avoid uneven glue thickness and broken glue. 4-stage frequency conversion speed regulation is selected, which greatly limits the proficiency of the operators and improves the operation efficiency.

以上就是為大家介紹的有關中空玻璃加工設備的詳細的介紹,希望對您有所幫助.如果您有什么疑問的話,歡迎聯系我們.我們將以的態度

The above is a detailed introduction of the insulating glass processing equipment. I hope it will help you. If you have any questions, please contact us.
